The Klein Tools ET910 is a USB digital meter and tester combination for most common USB-A ports, including Qualcomm Quick ChargeŽ ports. It accurately and reliably measures and displays the USB port voltage, current, capacity, energy, and resistance simultaneously. It can also test the maximum current delivery capability of the USB port with built-in fixed loads so user need not connect to an external load. It will function with any USB-A port that has the ability to deliver power. It requires NO batteries as it draws power from the power source to function.
Features:
3 to 20V DC; Current: 0.05 to 3A (monitoring mode)
Built-in test loads of 0.5A, 1A, 2A, and 3A; no external test load required
Continuously monitor up to 1000 hours of voltage, current, capacity/charge delivered, energy, and resistance (calculated)
Tests most common standard USB-A ports, including Qualcomm Quick ChargeŽ ports
Store and recall up to 10 readings
Voltage and current overload detection
Hi-resolution LCD for clear visibility in environments with low ambient lighting
Durable cable to allow easy access to hard-to-reach ports
Rugged, pocket-sized, and light weight Klein industrial design stands up to jobsite demands
Built to withstand a 6-Foot (2m) drop
No batteries needed; powered by the USB port being tested
Specifications:
Type: USB-A (Type A)
Application: USB Port Voltage, Current, Capacity, Energy, Resistance (Calculated), Max Current
Special Features: Current Test Loads: 0.5A, 1A, 2A, 3A
Voltage: 3 to 20V DC
Current: 0.05 to 3A
Capacity Used: 99,999mAh Maximum
Energy Delivered: 999Wh Maximum
Resistance: 400 ohms Maximum
Elapsed Time: Up to 999 Hours, 59 Min, 59 Secs
USB Compatibility: USB-A; Qualcomm Quick ChargeŽ Compatible
Drop Protection: 2 m (6.6')
Ingress Protection: IP20
Display: LCD
Material: Polymer
Overall Length: 4.31" (109.5 mm)
Overall Height: 0.98" (24.9 mm)
Overall Width: 2.15" (54.6 mm)
Weight: 2.8 oz (79.4 g)
Click Here to View the Operation Manual
|
|
|
 |
|
 |
|
