The NCVT-4IR from Klein Tools provides non-contact determination of AC voltage in cables, cords, circuit breakers, switches, outlets and wires; as well as infrared (IR) thermometer measurements, making it the perfect choice for HVAC professionals.
Features:
Designed specifically for HVAC applications
Provides non-contact determination of AC voltage in cables, cords, circuit breakers, switches, outlets and wires, as well as AC voltage in security, entertainment, communications, environmental control, and irrigation systems
Detects AC voltage from 12 to 1000V with visual and audible indicators
IR thermometer with user selectable F/C from -20 to 482F (-30 to 250C)
Convenient laser pointer also helps target 4:1 distance to spot ratio for IR temperature
Backlit LCD display with 0.1 degree resolution
Auto power-off conserves and extends battery life
Screw-thread battery cap with O-ring ensures dustproof and waterproof ingress protection
Lightweight, compact tool with pocket clip provides easy storage and quick access
Specifications:
Special Features: High-Pitched Continuous Beeping Sound
Batteries: 2 AAA
Voltage Range: 12 to 1000V AC
Standard: CAT IV 1000V
Weight w/Batteries: 2.8 oz (79 g)
Weight: 2.0 oz (57 g)
Overall Length: 6-1/4" (158.8 mm)
Overall Height: 1-1/4" (31.8 mm)
Overall Width: 1-3/16" (30.2 mm)
Klein Tool's NCVT-4IR Instruction Manual
|
|
|
