Active Return Drop Amplifier

Active Return Drop Amplifier


TTS PRICE: $50.99

STATUS:  IN STOCK

Free Shipping

Availability:
Normally Ships Same Day

PRODUCT CODE: HCDA-1FRA
QUANTITY:

PRODUCT DESCRIPTION


The HCDA Series is the top of the line CATV drop/subscriber amplifier. The HCDA amplifiers are unsurpassed in environmental ruggedness with sealed ports, powder coated paint, and an RFI hermetically sealed back plate. The HCDA-1FRA is the same quality drop amplifier as the rest of the HCDA Series, with the addition of reverse amplification to overcome return path loss.

Features:
  • 1 GHz Bandwidth
  • Hermetically Sealed Case & Ports
  • Low Noise Figure: 3 dB
  • Direct or Drop Line Powering Capable
  • High Return Loss
  • Surge Protected (IEE C62.41-1991, All Ports)
  • 130 dB RFI Shielding
  • LED Power Indicator

    • Specifications:
  • Power Supply (included): 12 VDC @ 200 mA
  • Power Inserter (optional): HRPI
  • Operating Temperature: -40° to +60° Celsius
  • Dimensions: 2.5" x 4.5"
  • Weight: 1 lbs.
  • Connectors: F-Type

    • Forward Path:
  • Frequency: 54-1000 MHz
  • Gain (+/- 1 dB): 15 dB
  • Flatness:±.5 dB
  • Maximum Output (157 Ch): 25 dBmV
  • Cross Mod: -75 dB
  • CSO: -62 dB
  • CTB: -75 dB
  • Noise Figure (+/- .5dB): 3 dB
  • Return Loss (In/Out): 20 dB
  • RFI \ Shielding Effectiveness: 110 dB

    • Reverse Path:
  • Fequency: 5-42 MHz
  • Gain: 10 dB
  • Flatness: ±.5 dB
  • Maximum Input: 45 dBmV
  • Maximum Output: 55 dBmV
    •
